  • <span style=”background-color: rgba(255, 255, 255, 0);”>Hi guys

    Wondering if anyone can shed a little light my way. I’m looking for a powered usb hub for my MacBook Pro, I run a Traktor S4, Ableton Push, Maschine, Audio 2 DJ Interface and occasionally a USB drive and some other things iPad /iPhone. I’ve just purchased the Advent 312 http://www.currys.co.uk/gbuk/computi…28377-pdt.html but sometimes when I boot the Mac up it doesn’t always power the Maschine or S4. Been looking at some other models and someone said that Native Instruments only use the dlink hubs but which model are these?

    Thanks in advance </span>

    Hi,

    Unfortunately the link you posted doesn’t work for me, so can’t see exactly what model you have.

    As a general rule, a USB-port has a maximum amount of power it can deliver. That’s laid down in the USB standard.

    For USB 2.0 it’s 500mA, for USB 3.0 it’s 900mA and for 3.1 (newest version since 2013) it’s a whopping 2000mA (or 2A which means 10Watt! @ 5Volt, as opposed to 2,5Watt for USB 2.0).

    Now, this is PER PORT! Let’s say you have an 8-port USB 2.0 hub and you want to use all of them for full power, the hub would need to have an external power supply that can supply 8 * 0,5A = 4,0A @ 5V. Quite frankly, a 4A power supply is a pretty big one.

    I just picked a random one:

    And you can see where it says capacity 5Watt. @ 5V that is a grand total of 1A 0r 1000mA. Divide by 4 ports and presto, with all ports going only 250mA per port. Half of what it could be.

    Long story short, you can get a USB 2.0 powered hub, but you’d have to check the supplied power adaptor can deliver 0,5A per port. Brand should not play a part. It’s really as simple as how much power do you need and how much can the hub supply. Normally with stuff like mice, memorysticks and even some external HDD’s it’s relatively low, but when you start hooking up stuff like full blown controllers and Maschine it soon starts to add up and there is just not enough power available.

    First rule of engagement, imho, is to always use external power on any device if it has that option (so the S4 for example, always use power adapter, not the USB only option).

    So, two steps to get going:

    1) use all units mentioned with their own power supply if at all possible (S4, Push – not the Maschine & Audio 2 DJ I think)

    2) Get a powered USB hub with a strong enough power supply

    Hope that helps & greetinx.

  • The forum ‘Digital DJ Gear’ is closed to new topics and replies.

Traktor S4 Download

The adapters and cables in this article work with these Mac computers and iPad Pro devices:

Usb C Hub Macbook Pro Traktor S4 Traktor pro 2 full crack. There's cmdr.exe for Windows and xmapper or something like that for Mac. The Thundermax unit itself is contained in a very nicely CNC machined case and is very durable.InstallationInstall is very straight forward. I would like to hear from Pioneer DJ official support personnel as well as from other users, about how Pioneer DJ mixers/interface and Rekordbox are performing over USB-C. Especially on the new macbook pro line up. I currently use a Macbook Air Mid-2013 core i5 1.3GHz 8GB RAM, with Traktor Scratch Pro, and the timecode works like a charm on a.

  • Mac models that have Thunderbolt 3 ports. These ports support both Thunderbolt 3 and USB-C connections.
  • Mac models that have a USB-C port. This port supports USB-C connections.
  • iPad Pro models that have a USB-C port. This port supports USB-C connections.

To find the right cable or adapter for your Mac or iPad Pro, use the information below to identify the connector on the end of the cable coming from your display, hard drive, camera, hub, or other device. Check the end meant to plug into your Mac or iPad Pro.

Thunderbolt 3

Usb C Hub Macbook Pro Traktor S4 Pro

If you're using an Apple Thunderbolt 3 cable or other Thunderbolt 3 cable with your display or other device, it will connect to your Mac without an adapter.

Pro

The Apple Pro Display XDR and LG UltraFine 5K Display use Thunderbolt 3.

USB-C

If you're using a mophie USB-C Cable with USB-C Connector or other USB-C cable with your device, it will connect to your Mac or iPad Pro without an adapter.

The LG UltraFine 4K Display uses USB-C.

USB-A

If you're using a USB-A cable with your device, use the Apple USB-C to USB Adapter, the Apple USB-C Digital AV Multiport Adapter, the Apple USB-C VGA Multiport Adapter, or another USB-C to USB-A adapter to connect your device to your Mac or iPad Pro.

Usb C Hub Macbook Pro Traktor S4Usb c hub macbook pro traktor s4 driver

To charge an iPhone, iPad, or iPod touch from a Thunderbolt 3 or USB-C port without one of these adapters, you can use the Apple USB-C to Lightning Cable instead.

Ethernet

If you're using an Ethernet cable with your device, use a third-party USB-C to Ethernet adapter, such as the Belkin USB-C to Gigabit Ethernet Adapter.

Thunderbolt or Thunderbolt 2

If you're using a Thunderbolt or Thunderbolt 2 cable with a Thunderbolt display or other device, use the Apple Thunderbolt 3 to Thunderbolt 2 Adapter.

This is the correct adapter for the Apple Thunderbolt Display.

Thunderbolt and Thunderbolt 2 are not the same as Mini DisplayPort . They have the same shape, but use different symbols on the cable and port.

Mini DisplayPort

If you're using a Mini DisplayPort cable with a Mini DisplayPort display, use a third-party USB-C to Mini DisplayPort adapter. Check with its manufacturer for compatibility with your Mac and display model.

Usb C Hub Macbook Pro Traktor S4

This is the correct solution for the Apple LED Cinema Display.

Mini DisplayPort is not the same as Thunderbolt or Thunderbolt 2 . They have the same shape, but use different symbols on the cable and port.

DisplayPort

If you're using a DisplayPort cable with your display, use a third-party USB-C to DisplayPort adapter or cable, such as the Moshi USB-C to DisplayPort Cable.

HDMI

If you're using an HDMI cable with your display, use the Apple USB-C Digital AV Multiport Adapter or a third-party USB-C to HDMI adapter or cable.

Pro

VGA

If you're using a VGA cable with your display, use the Apple USB-C VGA Multiport Adapter. Or use a third-party USB-C to VGA adapter, such as the Belkin USB-C to VGA Adapter.

DVI

If you're using a DVI cable with your display, use a third-party USB-C to DVI adapter or cable. Check with its manufacturer for compatibility with your Mac and display model.

Learn more

  • You can use your USB-C Power Adapter and charge cable with any Thunderbolt 3 or USB-C port on your Mac or iPad Pro.
  • If you have an Apple TV connected to your TV, projector, or other display, you can use AirPlay to wirelessly stream video to that display, or extend the desktop of your primary display.
  • Learn about using external monitors with your Mac.
  • Learn more about using the USB-C port on your iPad Pro.
